Pusher
Technical Specification
A charging pusher is an Electro-Mechanical or Hydraulic device which is used for
feeding or charging of raw material (Like ingots, billets etc) into the reheating
furnace.
Various components which are used in the manufacturing of a Charging pusher are:
Heavy steel slab frame, pushing screw with pushing slab, multi stage type reduction
gear box or a hydraulic power pack with alloy steel shafts in case of a hydraulic
pusher.
Depending on the raw material to be feed i.e., scrap / mill rolls, ingots / billets
or heavy blooms and their sizes, the mechanical or hydraulic type pusher is designed
and supplied.
We at “THE KAMAL ENGINEERING” provide Pusher as per the following
configuration.
|
PUSHING CAPACITY |
200 TON |
|
PER HOUR CAPACITY |
30 TON |
|
POWER PACK |
350 Ltr |
|
MOTOR CAPACITY |
35 H.P. |
|
BASE FRAME |
50mm Plate |
| PUSHING SLAP | 200mm |
| CYLINDER SIZE | 200mm |
| STROKE | 1200mm |
