Hot Saw

Technical Specification

We manufacture these Hot saws under the strict observation and supervision of professionals.

The Hot Saw is placed before the cooling bed to cut the rolled sections to the required lengths. One no Fixed Hot saw is placed before the cooling bed to cut the front end of the sections Traveling Hot saw is placed at a distance from the Fixed Saw. The distance can be adjusted equal to the travel of the Hot saw along the axis of rolling. Number of traveling Hot saw required depends on the length of the rolled section & the number of cuts required along the length of the section.

The Hot saw Blade of the Fixed & traveling Saw, plunges at right angle to the rolling axis cutting the section at the front end as well as at the required lengths by Traveling hot saw After cutting the grip is released and the cut section is delivered on the cooling bed.

Advantage:
Because of the sliding type saw, heavier sections can be cut with better straightness compared to pendulum type saw.

We at “THE KAMAL ENGINEERING” provide Hot Saw as per the following configuration:

1.) Rolled section is gripped on the run-out roller table
2.) Cuts heavier section with better straightness
3.) Heat resistant, Superior durability, Precise & sharp tooth and Corrosion free
4.) Easily cuts beam, channel and angle
5.) Increases the productivity of extrusion system
6.) Cuts every billet to the uniform size
7.) Removes trim front end
